Reverse Backup Camera,170 Degree Wide View Angle Universal Car Front/Side/Rear View Camera,2 Installation Options,Removable Guildlines,Mirror Non-Mirror Image,12V only

Description

Chuanganzhuo CARA002 Backup Back up Camera,Smallest HD Color CMOS Waterproof
Vehicle Car Front Side Rear View Camera,Optional Distance Scale
Line,Mirror/Non-Mirror Image,16.5mm,BlackOverview: This camera can be used as
backup camera,side view camera and front camera,It is with mirror / non-mirror
switcher and Image Guide Line (Yes/No) Switcher enable you decide freely the
mode of the camera. you can install it at the anyplace of your car you
wanted.after you connect it with your monitor,you will be able to see
everything that the camera can see. it like another eye to keep you safe and
secure because you will always know what’s going on around you. Note: this
camera is a backup camera with distance scale line as default. White Switch
Wire: Distance scale Line (Yes/No) Switcher Green Switcher Wire: Mirror/non-
Mirror switcher 1.If you need a backup camera with distance scale line,you
just install it right now without any operation. 2.If you need a backup camera
without distance scale line,please cut the white wire. 3.If you need a front
camera with distance scale line,please cut the green wire. 4.If you need a
front camera without distance scale line,please cut the both green and white
wire.Note:if you suddenly want to convert backup camera to front view camera
or convert front view camera to backup camera,please Switch off electrical
power and then connect them again,so it can convert successfully.
Specification: Image sensor: PC7070 TV System:NTSC Diameter size:18.5mm
Resolution:420 TV line S/N Radio: better than 48db Video output: RCA
connector, 1.0vp-p,750hm Power: 12V DC Waterproof grade: IP67 Effective
Pixels:648X488pixelsfront view camera with same appearance,please search
B01C58TW12 on Amazon;

Features:

• This universal camera is perfect for mounting on your car. Its got a wide angle,connect to a monitor in your car,and youll be able see everything behind you or in front of you on the screen
• Easy to install: 2 Installation options,you could choose bracket mounting or flush mounting as per your case
• Rear/Front Switchable: Optional Customized Distance Scale Lines & Mirror/Normal Image Switchable – You Can Use it as Rear View Backup Camera or Front/Side Camera Note: By default this is a reverse camera (mirror image) with distance scale line
• 170 Degree Wide View Angle to help you see blind area where your eyes can't reach.Work with your head units or aftermarket LCD/TFT displays with standard RCA input only,Suitable for variety of vehicles: car, mini-truck, mini-van etc,12V working Voltage ONLY,Support NTSC only
• Reliable and friendly customer service,1 Year Warranty,Ready to respond within a 24 hour time frame,30-Day Money Back Guarantee

Product Details:

• Brand: Chuanganzhuo
• Screen Size: 2 Inches
• Lux rating: 48 Lux
• Compatible Devices: Monitor
• Display Technology: LCD
• Installation Type: Surface Mount
• Video Capture Resolution: 420
• Voltage: 12 Volts
• Optical Sensor Technology: CMOS
• Lens Type: Wide Angle
• Package Dimensions: 5.2 x 3.23 x 2.13 inches
• Item Weight: 7.4 ounces
• Item model number: CARA002
• Is Discontinued By Manufacturer: No
• Display technology: LCD
• Other display features: Wireless
• Color: Black
• Manufacturer: Chuanganzhuo
• Country of Origin: China
• Date First Available: December 23, 2014
