Kidde 21026063 AC Hardwired Smoke Detector Alarm with 9V Back up and Front Load Battery Door
Description
The Kidde i4618 is an AC/DC powered ionization smoke alarm
that operates on a 120V power source with 9V battery backup This alarm uses
ionization sensing technology Ionization sensing alarms may detect invisible
fire particles (associated with flaming fires) sooner than photoelectric
alarms Photoelectric sensing alarms may detect visible particles (associated
with smoldering fires) sooner than ionization alarms. SMOKE ALARM
FEATURES • Model ADC features a False Alarm Control which, when activated,
quiets unwanted alarms for up to 15 minutes. • This smoke alarm is powered by
120V AC and a 9-volt battery back-up source. AC/DC smoke alarms offer added
protection in the event of a power failure or a drained battery. • Unique
power connector prevents interconnection with incompatible smoke alarms or
security systems. • This smoke alarm may be interconnected with as many as 11
other Firex model FADC, AD and ADC smoke alarms, or as many as 6 Firex model
ADH heat alarms for a total of not more than 18 interconnected devices. •
Optional tamper-resist feature can serve as a safeguard against tampering. •
Unique “battery missing” lockout. The smoke alarm will not attach to the
mounting bracket if a battery is not in the battery pocket. • Improperly
connected or weak battery signal. The smoke alarm will sound a short beep
about once a minute if the battery is weak or improperly connected. • Separate
green and red LEDs indicate that the smoke alarm is receiving AC power,
working under normal operation, in alarm, or under false alarm control. • Loud
alarm horn—85 decibels at 10 feet—sounds to alert you to an emergency. • This
alarm incorporates the internationally recognized horn signal for evacuation.
During alarm mode, the horn produces three short beeps followed by a 2 second
pause and then repeats. This pattern is somewhat different than the previous
alarm sound, which continually beeped. • Test button checks smoke alarm
operation. Model ADC also features a False Alarm Control which, when
activated, quiets unwanted alarms for up to 15 minutes.
Features:
- Easy Installation – Front battery pull tab allows battery activation without removing alarm from mounting bracket. Large mounting base makes mounting easier, protects surface paint from dirt and covers imperfections. Pre-stripped wiring harness with easy off cap does not require stripper tool. Tinned strands increase conductivity and wire nut grip.
- Fewer callbacks – Large centrally located Test/Hush alarm control button. Dust cover protects sensor from contaminates during construction reducing nuisance alarms.
- User-friendly features – Easy access front loading battery door. Battery backup provides protection in case of power failure. Interconnectable with up to 24 devices (of which 18 can be initiating) including smoke, CO and heat alarms. See users guide for complete instructions.
- Alarm memory flashes red LED indicating which unit was the initiating alarm in interconnected system. Temperature range: 40 degree Fahrenheit to 100 degree Fahrenheit
- Tamper resist locking feature deters alarm theft. Audio Alarm-85dB at 10feet
Product Details:
- Brand: Kidde
- Power Source: Hardwired
- Color: White
- Product Dimensions: 4"D x 4"W x 2"H
- Item Weight: 8 Ounces
- Alarm: Smoke Alarm
- Operating Humidity: 5% to 95% relative humidity, non-condensing
- Upper Temperature Rating: 37.8 Degrees Celsius
- Sensor Type: Ionization
- Brand: Kidde
- Power Source: Hardwired
- Color: White
- Product Dimensions: 4"D x 4"W x 2"H
- Item Weight: 8 Ounces
- Alarm: Smoke Alarm
- Operating Humidity: 5% to 95% relative humidity, non-condensing
- Upper Temperature Rating: 37.8 Degrees Celsius
- Sensor Type: Ionization
- Manufacturer: Kidde Safety
- Part Number: 21026063
- Item Weight: 8 ounces
- Item model number: i4618
- Is Discontinued By Manufacturer: No
- Size: 1 Pack
- Pattern: Detector
- Item Package Quantity: 1
- Included Components: User Guide, Wiring Harness, Smoke Alarm
- Batteries Included?: Yes
- Batteries Required?: Yes
- Battery Cell Type: Alkaline
- Date First Available: November 7, 2014
